LG Mono X® 72cell comes with the enhanced performance limited warranty. The initial degradation has been improved from -3% to -2%, and the annual degradation has also changed from -0.7%/yr to -0.6%/yr.
LG Mono X® 72cell has improved the initial degradation by applying LG’s new LiLY(LID-improvement for Lifetime Yield) Technology, which controls formation of Boron-Oxygen pair, the key factor of LID.
In addition to the enhanced performance limited warranty, LG has extended the limited product warranty of LG Mono X® 72cell for additional 2 years with its newly reinforced frame design.
LG Mono X® 72cell is carefully designed to benefit installers by allowing quick installation with a weight of just 44.75 lb. and better grips.
LG modules are carefully designed to benefit installers by allowing quick and easy installations throughout the carrying,grounding, and connecting stages of modules.
Mechanical Properties
Cells
6 x 12
Cell vendor
LG
Cell type
Monocrystalline / P-type
Cell dimensions
156.75 x 156.75 mm / 6 inches
# of busbar
3
Dimensions (L x W x H)
1960 x 1000 x 46 mm 77.17 x 39.37 x 1.81 inch
Front Load
60 psf
Rear Load
60 psf
Weight
20.3 ± 0.5 kg / 44.75 ± 1.1 lbs
Connector type
MC4
Junction box
IP 67 with 3 bypass diodes
Length of cables
1200mm x 2 ea / 47.24 x 2 ea
Frame
Anodized aluminium
Glass
High transmission tempered glass
Certifications and Warranty
Certifications
UL 1703, ISO 9001, IEC 62716 (Ammonia Test)* IEC 61701 (Salt mist corrosion test)*
Module Fire Performance (UL1703)
Type 2 (UL1703)
Product warranty
12 years
Fire Rating (for CANADA)
Class C (ULC/ORD C1703)
Output warranty of Pmax
Linear warranty*
*
in progress
**
1) 1st year: 98%, 2) After 2nd year: 0.6%p annual degradation, 3) 83.6% for 25 years
Temperature Characteristics
NOCT
46 ± 3 °C
Pmax
-0.42 %/°C
Voc
-0.30 %/°C
Isc
0.03 %/°C
Electrical Properties (STC*)
MPP voltage (Vmpp)
37.7
MPP current (Impp)
9.02
Open circuit voltage (Voc)
46.4
Short circuit current (Isc)
9.54
Module efficiency (%)
17.4
Operating temperature (°C)
-40 ~ +90
Maximum system voltage (V)
1000
Maximum series fuse rating (A)
20
Power tolerance (%)
0 ~ +3
*
STC (Standard Test Condition): Irradiance 1000 W/m2, module temperature 25 °C, AM 1.5 / The nameplate power output is measured and determined by LG Electronics at its sole and absolute discretion.
Electrical Properties (NOCT*)
Maximum power(Pmax)
251
MPP voltage (Vmpp)
34.6
MPP current (Impp)
7.26
Open circuit voltage (Voc)
43.3
Short circuit current (Isc)
7.68
*
NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m2, ambient temperature 20 °C, wind speed 1 m/s
